screen printing fabric mesh

Description

According to the use of silk screen called silk screen printing network, polyester filter

• Specifications:8T-165T (20mesh/inch-420mesh/inch)
• Color:white,yellow,black,orange,etc white and yellow is mainly used to printing,Black used in the sound more.Other colors on request
• Weave:Plain weave
• Width:50-360cm,Conventional size has 1m,1.27m,1.65m,
• If the quantity is big,the special size can be customized,.

Application

Silk screen performance is good, high strength, eye hole accurate. Structural strength, good resistance to printing, high mesh accuracy, high dimensional accuracy, good dimensional stability, good resistance to drug performance, good ink performance; pull the net after the stability of the stability, printing accuracy and stability of the structure, can withstand Higher tension, low elongation; long life, in a very small net distance, and ink stripping performance is good; for a variety of large signs, billboards. Printing, printing and dyeing, ceramics, electronic components, glass, industrial filtration, food chemical paper, plastic, silk chemical fiber and other industries

Feature advantage

1, screen printing adaptability is very strong, wide range of applications.
2, screen printing can not only monochrome printing, you can also color and color printing network.
3, screen printing products, light resistance than other types of printed products, light fastness, more suitable for outdoor advertising, signs of use.
4, screen printing can be a large area of printing, today's screen printing products, the most significant up to 3 m × 4 m, or even greater

Specification

Features of Polyester Printing Mesh:

• High tension threshold and breaking point
• high modulus,low elongation monofilament polyester yarn
• Resist to chemicals, abrasion, heat and moisture
• Minimal tension loss during stretching process
• Improved registration due to stable fabric tension
• Good antistatic
• No surface treatment

Application of Polyester Printing Mesh

• Textile printing
• T-shirt printing
• ceramic printing
• glass printing
• PCB printing industry.

Tips of Best Polyester Printing Mesh for work:

• 20 and 40 mesh is used mostly for glitter inks that need a very open mesh for printing.
• 60 mesh is usually used for printing smaller glitter and most shimmer inks.
• 80 mesh is also used for printing shimmer inks and for laying down thick layers of ink for high-density printing. It also works well for printing foil adhesive.
• 110 mesh makes printing white and other thick inks easy. It is ideal for spot color printing since it holds less detail than 155 mesh and lays down a thick layer of ink for maximum coverage.
• 120 mesh is one of the most rifely mesh sizes in screen printing. It works great for printing white ink and other colored inks that have a thicker viscosity.
• 155 mesh is great for general purpose textile printing with basic to semi-fine detail. It will hold a little finer detail than a 110 mesh while also working well with thinner inks.
• 200 mesh is great for printing more detailed prints that need a thinner layer of ink than a 155 mesh. It works very well with thinner inks and is a good middle-range mesh size.
• 230 mesh is great for high-end fine detail printing. A 230 mesh can hold halftones very well and also lets a little more ink through then a 305 mesh. The yellow color prevents light from reflecting through the threads of the mesh and keeps a sharper image when burning.
• 280 mesh screens are great for high-end fine detail printing. A 280 mesh can hold halftones very well and also lets a little more ink through then a 305 mesh.
• 305 mesh holds extremely high detail, letting through only a thin layer of ink. This allows for a very soft hand on the garment and is great for use in printing halftones and process prints. The yellow color prevents light from reflecting through the threads of the mesh and keeps a sharper image when burning.

Polyester network name polyester network, also known as silk screen yarn, printing network, printing screen.
The use of foreign technology in the mainland production of a network of yarn, white and yellow two, commonly used width: 127CM / 160CM / 165CM. Uniform thickness of yarn, high-quality anti-static effect, high tension and wear resistance.

Main use: Suitable for all types of printing, including different formats and area of the image, laser discs, decorative tiles, glass surface, sporting goods, textile and industrial printing.

Features of Polyester Printing Mesh:

• High tension: with a high degree of breaking strength, wire mesh tension was significantly higher than ordinary screen.
• High stability: good stability of the wire mesh elongation is minimal; the same time, the tension in the printing process to maintain a good stability, to ensure the quality of printing and screen life.
• High precision: the maximum mesh up to 500 mesh / cm, screen thickness, opening, wire diameter error control in the smallest range, is the high-precision line printing and dot printing the best choice.
• High wear resistance: the use of high-quality fiber to do raw materials, wire mesh surface after special treatment, can withstand high pressure friction times, so that the screen has a high degree of security and resistance to printing times.

Application of Polyester Printing Mesh

• Textile printing
• T-shirt printing
• ceramic printing
• glass printing
• PCB printing industry.

Description of polyester printing mesh

1. Description

Anping county PFM screen co.,ltd started the manufacturing of 100% polyester screen printing mesh since 1997,and has 83 sets P7100 and P7150 Sulzer polyester mesh weaving looms imported from Switzerland and 46 sets of other machines and devices including automatic warp arranging machine imported from Germany,heat shaping machine test facilities.

2. Application

1. Textile prinitng industry.

2. Electronics printing.

3. Ceramics printing industry.

4. Solar battery printing,liquid crystal display printing.

5. Filtration in aviation,airspace,petrochemical and food industries.

6. Glass printing industry,such as glass bottle,glass maquillage bottle.

7. High-density printed circuit board with high printing precision requirement.

8. Filtration in aviation,airspace,petrochemical and food industries.

Feature advantage

1. Made of 100% polyester monofilament yarns.

2. Low elongation at high tension.

3. Excellent printing effect.

4. Has stable physical property.

5. Nice appearance and standard size.

6. High durablity and best tensility.

7. Excellent capability for rub and face stretch.

8. Solvent resistance,heat resistance,chemical resistance and madicine resistance.

1. Description

High quality is guaranteed by the usage of high tensile, low elongation, direct spinning monofilament 100% polyester yarns (not split yarns which are weak), strict quality control in each production process and final inspection by our Quality Control System. At Final Inspection, every meter of fabric is inspected for any kind of fault according to our Quality Control System. Only tested, approved, without-fault, A-Grade printing screen is sold to our customers.

2. Application

Our polyester printing mesh are of high quality, high precision,low elongation, high strength with a wide range from 25mesh to 420mesh,annual output is up to 800,000m².

Our products are extensively used for screen printing, plate making in electronic, textile, and ceramics industry etc., also used for liquid filtering in aviation, oil and chemical high technology fields.

Feature advantage

1. High tension and low elongation
2. Precision bore, well-distributed, stabilization
3. Accurate printing precision control
4. Time-dependent stability and good cohesion with sensitive emulsion
5. Accelerated printing speed
